I-38

15. Power Supply

Power is provided by the power-supply unit. Power voltages are as shown below.

POWER SUPPLY

High Voltage Solenoid UP 100V

GP 120V

DGT2IIXG 100V

PRO 80V

MARKIII 100V

Low Voltage MX100IIXG

DGPIIXG

H SENSOR 5V, 20V

K SENSOR 5V

CTRL 5V

MPX100IIXG H SENSOR 5V, 20V

K SENSOR 5V

CTRL 5V

MN 5V, ±12V

MD 5V, 12V

PRO/DGPS H SENSOR 5V, 12V

K SENSOR 5V, 12V

CTRL 5V

MN ±15V

MD 5V, 12V

DGT2IIXG H SENSOR 5V, 12V

K SENSOR 5V, 12V

CTRL 5V

MN 5V, ±12V

MPX70 K SENSOR 5V, 12V

CTRL 5V

MN 5V, ±12V
