II-43
[One key measure]
Item Operation Response
Start-up 9F+11G+Power ON
Chord Once/sec.
Ready Wait for 30-40sec. (stabilize the output of light-emit-
ting components)
Select key Play the appropriate key
Note that was played Once/sec.
Open position measurement Pull the key shutter up and out of the sensor unit.
(Raise the key.)
Write to RAM With the keyboard raised.
Press the damper pedal once
Note Double continuous stroke
Rest position measurement Lightly stroke near the key button, so that the key is
not floating.
Write to RAM Press the damper pedal once
Note Triple continuous stroke
End position measurement Play the appropriate key.
Write to RAM Press the damper pedal once Chord Once/sec.
Store to flash memory Press the soft pedal once 76C Triple or four continuous
stroke
To Next Page
