2 En
PREPARATION
X Top panel
1 iPod dock: Set an iPod.
2 USB port (☞ P. 7)
When the USB device is not in use, set the USB cover to
protect the connector.
3 : Press to turn the system on/off.
Time is displayed even when the system is off.
y
• Press and hold on the top of the unit for more than 3
seconds to set the system to power save mode. All the
information on the front panel display is not displayed
in power save mode. This can reduce power
consumption. To cancel power save mode, press on
the top of the unit.
• Even in system off/standby mode, the alarm function is
available.
4 DIMMER:
Setting brightness of the front panel
A (auto) 3 (brightest) 2 1 (darkest) back to A
y
When A (auto) is set, the brightness of the front panel is
adjusted automatically depending on the brightness of the
room.
5 ALARM: Alarm on/off (☞ P. 13)
6 SET: Alarm setting (☞ P. 11)
7 SNOOZE/SLEEP (☞ P. 13, 14)
8 TUNING (☞ P. 8, 10)
9 Audio control buttons: Skip, search backward/
forward, play/pause, stop
0 : Ejecting the CD.
A Disc slot (☞ P. 7)
B DISPLAY: Switching the DAB information display
(☞ P. 9)
C DAB information display: Displaying DAB
information (☞ P. 8)
NAMES OF PARTS AND THEIR FUNCTIONS
DISPLAY
Dock
Adaptor
Set your iPod in the iPod dock.
y
An iPod is charged when set in the iPod dock. During power save mode, the iPod is not
charged.
• Be sure to use a dock adaptor that is compatible with your iPod. If you do not use the
adaptor or the adaptor is not compatible, the connection could be loose or poor, which
could cause damage to the connector.
• If an iPod in protective case is connected by force, the connector may be damaged.
Remove the protective case before connection.
• When the iPod is not in use, set the dock cover to protect the connector.
Notes
Note
