NAMES OF PARTS AND THEIR FUNCTIONS
3 En
■ Rear panel
9 ALARM: Alarm on/off (☞ P. 5)
0 SET: Alarm setting (☞ P. 4)
A NFC mark: Allows easy pairing with NFC
technology (☞ P. 11).
B SNOOZE/SLEEP (☞ P. 5)
C MEMORY (☞ P. 8)
D DIMMER: Sets the brightness of the top and front
panel
A (auto) 3 (brightest) 2 1 (darkest)
back to A
y
When A (auto) is set, the brightness of the top and front
panel is adjusted automatically according to the
brightness of the room.
E TUNING (☞ P. 8)
■ Extending rod antenna
15V : Connect the supplied
AC adaptor and power cable.
AUX: Connect an external
device. (☞ P. 9)
FM Rod Antenna
(See below.)
ALARM TYPE switch (☞ P. 4)
CLOCK switch (☞ P. 4)
• When you listen to FM, extend the
antenna.
• If FM reception is poor, change the
height or direction of the antenna, or
relocate the unit.
Notes
FM Rod Antenna
To Next Page
