8-27
8
3. Remove the center bottom panel by re-
moving the bolts.
4. Place a container under the engine to col-
lect the used coolant.
5. Remove the radiator cap.
6. Remove the coolant drain bolt and its
gasket to drain the coolant from the en-
gine and radiator.
1. Center bottom panel
2. Bolt
22
22
1
1. Radiator cap
1
