8-23
LIGHTING SYSTEM
ELEC
NOTE:
YP******
1. Fuse
Refer to “CHECKING SWITCHES” section.
Repalce the fuse.
NO CONTINUITY
CONTINUITY
:
YP******
2. Battery
S Check the battery condition.
Refer to “BATTERY INSPECTION” section
in CHAPTER 3.
S Clean battery terminals.
S Recharge or replace battery.
INCORRECT
CORRECT
YP******
3. Main switch
Refer to “CHECKING SWITCHES” section.
Replace the main switch.
NO CONTINUITY
CONTINUITY
YP******
4. Lights switch
Refer to “CHECKING SWITCHES” section.
Replace the right handlebar switch.
NO CONTINUITY
CONTINUITY
YP805010
TROUBLESHOOTING
IF THE HEADLIGHT, HIGH BEAM
INDICATOR LIGHT, TAILLIGHT,
MARKER LIGHT AND/OR METER LIGHT
FAIL TO COME ON.
Procedure
Check:
1. Fuse (Main)
2. Battery
3. Main switch
D Remove the following parts before trouble-
shooting.
1) Tail cover
2) Cowling body
D Use the special tools specified in the trouble-
shooting section.
Pocket tester:
90890-03112
4. Lights switch
5. Dimmer switch and pass switch
6. Wiring connection (entire lighting system)
To Next Page
