REAR SHOCK ABSORBER ASSEMBLY
4-60
Removing the rear shock absorber assembly
Order Job/Parts to remove Q’ty Remarks
13 Collar 2
14 O-ring 2
15 Dust seal 2
16 Bushing 1
17 Stopper ring 1
M
56 N・m (5.6 kgf・m, 41 lb・ft)
53 N・m (5.3 kgf・m, 39 lb・ft)
10 N・m (1.0 kgf・m, 7.4 lb・ft)
M
M
M
LS
M
LS
New
13
16
15
14
15
New
14
New
New
13
17
