YCO-1127-12-08
PPC-300WP Operation Manual
Name and Function of Parts
Specications
Weighing system: Strain-gauge load cell
Platform: 9.1” x 7.9” (232 x 202 mm), stainless steel
Capacities and divisions:
Kilogram Pound Ounce Pound-Ounce* Max. Tare
2 kg x 0.001 kg 4.4 lb x 0.002 lb 80 oz x 0.05 oz 5 lb x 0.05 oz Capacity
4 kg x 0.002 kg 10 lb x 0.005 lb 160 oz x 0.1 oz 10 lb x 0.1 oz Capacity
10 kg x 0.005 kg 22 lb x 0.01 lb 352 oz x 0.2 oz 22 lb x 0.2 oz Capacity
20 kg x 0.01 kg 44 lb x 0.02 lb 704 oz x 0.5 oz 44 lb x 0.5 oz Capacity
* Combined units, such as pound-ounce, are not legal-for-trade.
Weight display: PPC-300WP - single display
Type: 7 segment LCD
Character size, etc.: 0.5” (13.5 mm) (W) x 1.2” (30 mm) (H), 5 digits
Functions: One touch tare, battery charge indicator, auto-off timer, and check-
weighing, packing and grading functions
Housing: Upper - 304 Stainless Steel
Lower - ABS resin
Enclosure Rating: IP68 when sealed by Yamato authorized technicians,
IP65 otherwise.
Optional equipment: AC adaptor (use voids watertight seal)
Power supply: 6 VDC - four “D” size batteries or optional AC adaptor
Consumption: 0.07 W (max.)
Battery life: ~ 1400 hours of continuous use with alkaline batteries
Operating temperature: 14°F to 104°F (-10°C to 40°C)
Operating humidity: 30% to 80% relative humidity (no condensation)
Weight: 3.7 kg
II Description
