16
Parameter# 02: Number of Grading Ranks
At grading function, the restriction of number of grading rank can increase the registered items
numbers. Set the value with the greatest number of ranks in your handling items. The relation
between rank numbers and items numbers that can be registered at maximum is as followings.
< Grading Function >
No. of Rank Max. Item No. No. of Rank Max. Item No. No. of Rank Max. Item No.
02 66 items 07 24 items 12 15 items
03 49 items 08 22 items 13 14 items
04 39 items 09 19 items 14 13 items
05 33 items 10 18 items 15 12 items
06 28 items 11 16 items
Parameter# 03: Buzzer
When operating the fixed weighing function or checkweighing function, buzzer can be sounded in
the setting range at stable.
Parameter# 04: Rank judgment
At grading function, when you want to judge the rank at only stability after placing items on the pan,
set the parameter # 4 at 001.
Parameter# 05: Auto-off Timer
The auto-off timer can be selected by changing the setting value.
Parameter# 06: Auto-tare at fixed weighing function
At fixed weighing function, when you want to tare off a container weight automatically, set the value
at 001. When the scale displays “0”, the weight of anything placed on the pan first time is tared off
automatically.
Parameter# 07:
Flicker of weight display
At fixed weighing, checkweighing and grading function, if you want to flicker the display, set the
parameter# 7 at 001, 002, 003, 004 or 005. At grading function, the display flickers in any setting
(001 to 005).
Parameter# 09:
Gravity compensation
The UDS-1V-WP (non-trade use) is equipped with the function of Gravity compensation. It is
available to set the value that is appropriate for the area the scale is used. The value can be
evaluated by the below calculating formula.
Calculating formula
: (Acceleration of Gravity (m/s
2
) – 9.7600) x 10000 / 5 + 30 (offset)
*9.7600 = Acceleration of Gravity at Akashi, Japan
To Next Page
