SPECIFICATIONS
The appearance and specifications are subject to change without notice for improvement.
1. Name of the scale (Model): UDS-1V-WP
2. Weighing system: Strain-gauge load cell
3. Dimensions of the platform: 232 mm x 202 mm
4. Capacity and Increment
Weighing capacity Minimum Increment Minimum capacity Maximum tare
3 kg 1 g 20 g 3 kg
6 kg 2 g 40 g 6 kg
15 kg 5 g 100 g 15 kg
5. Display
Type: Liquid crystal display tube 7 segments LCD
Character size: 13.5 mm (w) x 30.0 mm (H)
Indicator
Weight display Max. 5 Digits
Center zero indicator Lights up at center-of-zero range
Tare indicator Lights up at tare operation
Stable indicator Lights up at stable
Battery level indicator Lights up in accordance with the battery life at battery operation
Fixed weighing function Flashes at setting the data of items
Lights up at Fixed weighing function
Checkweighing function Flashes at setting the upper/ lower limits of items
Lights up at Checkweighing function
Grading function Flashes at setting the weight of each rank
Lights up at Grading function
6. Functions
Tare One-touch tare
Fixed weighing function Max. 99 items can be registered.
Checkweighing function Max. 99 items can be registered.
Grading function Max.15 ranks at 12 items or max. 2 ranks at 66 items can be registered.
Battery level checker Shows the remaining battery level by 3 levels at battery operation.
Auto-off timer Power off automatically after the setting time passes at battery operation.
Flashing weight-display is available at Fixed weighing and Checkweighing function.
7. Housing material: Stainless steel SUS304 (Upper housing & Pan)
ABS resin (Base)
8. Waterproof classification IP68
9. Range of operating temperature: -10˚C to +40˚C
10. Range of operating humidity: 30% R.H to 80% R.H. (no condensation)
11. Option: AC adaptor
