21
GRADING FUNCTION
Application : Sorting items up to 15 ranks
How to weigh : Store the lower limits of each rank of the items on the scale and display the rank of the
item based on the stored lower limits.
Features : 1) Stating the rank in figures instead of the weighing value avoids man-caused errors.
2) Stating the rank in figures speeds up the sorting work.
Stored values : 1) The lower limits of each rank
2) The upper limit of the upper rank
Registered item No. : In case of sorting items to 2 ranks, max. 66 items are available,
In case of sorting items to 15 ranks, max. 12 items are available.
e.g.) Sorting the item to 2 ranks.
0 g The lower limit The lower limit The upper limit Full capacity
of Rank 1 of Rank 2 of Rank 2
OUT OF RANK
RANK 1
OUT OF RANK RANK 2
