D. G-codes/M-codes
See the document [99 Supplement] for details.
G-codes
High-speed machining mode OFF
High-speed machining mode ON
High-accuracy mode (Geometry compensation)
Note 1: The geometry compensation reduces geometry errors caused by the delay in the
smoothing circuits and servo systems.
Note 2: The high-speed machining mode features high-speed execution of free form programs
such as die and mold machining approximated by fine increments data.
Combined with the geometrical correction function, it produces high quality surface
finish.
High-accuracy mode
Modal spline interpolation
Note 1: is G-code used by sample program.
Note 2: G61.2 is a geometry compensation with fine spline interpolation feature for a further
better quality surface for the CAM-made minute increments block by block data
operation.
