4JH4AE - C-Type Instrument Panel
Color
Coding
Description
R Red
B Black
W White
L Blue
RB Red / Black
LB Blue / Black
YW Yellow / White
YB Yellow / Black
YG Yellow / Green
WL White / Blue
WB White / Black
WG White / Green
GR Green / Red
O Orange
WBr White / Brown
1 Starter Switch
2 Stop Switch
3 Tachometer / Hourmeter
4 Buzzer
5 Lubricating Oil Low Pressure Alarm
6 Coolant High Temperature Alarm
7 Water in Sail Drive Seal Alarm
8 Battery Low Charge Alarm
9 Relay (for 2 station - Optional)
10 Fuse (3A)
11 Starter Switch
12 Stop Switch
13 Tachometer / Hourmeter
14 Buzzer
15 Seawater
16 Fuel Filter
17 Water in Sail Drive Seal Alarm
18 Battery Low Charge Alarm
19 Oil Pressure Meter / Alarm
20 Coolant Temperature Meter / Alarm
21 Air Heater
22 Engine Stop Solenoid
23 Stop Relay
24 Starter Relay
25 Starter
26 Coolant High Temperature Switch
27 Lubricating Oil Low Pressure Switch
28 Alternator (Optional)
29 Alternator
30 Water In Sail Drive Seal Sensor (on
Sail Drive)
31 Water in Sail Drive Seal Sensor
Amplifier (Sail Drive Only)
32 Battery (Optional)
33 Battery
34 Oil Pressure Sensor (Optional)
35 Coolant Temperature Sensor
(Optional)
36 Fuel Feed Pump (4JH4AE Only)
SYSTEM DIAGRAMS
JH4 Series Operation Manual 123
