Tightening Fasteners
Use the correct amount of torque when you tighten fasteners on the engine.
Applying excessive torque may damage the fastener or component and not enough
torque may cause a leak or component failure.
The tightening torque in the Standard Torque Chart should be applied only to the
bolts with a “8.8” head (JIS strength classification: 8.8). Apply 60% torque to
bolts that are not listed. Apply 80% torque when tightened to aluminum alloy.
When lock adhesive is applied, decide separately.
When seal washer applied, torque is 34 ± 5 N·m (25.1 ± 3.7 ft-lb).
Bolt Diameter x
Pitch (mm)
M6x1.0 M8x1.25 M10x1.5 M12x1.75 M14x1.5 M16x1.5
Tightening
Torque
N·m 10.8 ± 1.0 25.5 ± 3.0 49 ± 5.0 88.2 ± 10.0 140.0 ± 10.0 230.0 ± 10.0
ft-lb 8.0 ± 0.7 18.8 ± 2.2 36.2 ± 3.7 65.1 ± 7.4 103 ± 7.2 170 ± 7.2
Taper Plugs 1/8 1/4 3/8 1/2
Tightening
Torque
N·m 9.8 19.6 29.4 58.8
ft-lb 7.4 14.5 21.7 43.2
Pipe Joint Bolts M8 M10 M12 M14 M16
Tightening
Torque
N·m 14.7 ± 2 22.5 ± 3 29.4 ± 5 44.1 ± 5 53.9 ± 5
ft-lb 10.9 ± 1.5 16.6 ± 2.2 21.7 ± 3.7 32.6 ± 3.7 69.8 ± 3.7
