PRODUCT OVERVIEW
16 JH Series Operation Manual
NAMEPLATES
The nameplates of YANMAR 3/4JH
common rail series engines are shown in
Figure 7. Check the engine’s model,
output, min
-1
and serial number on the
nameplate. Please replace if damaged or
lost.
The engine nameplate is attached to the
engine rocker arm cover.
Figure 7
The marine gear nameplate (Figure 8) is
attached to the marine gear. Check the
marine gears model, gear ratio, oil used
and serial number.
Figure 8
The sail drive nameplate (Figure 9) is
attached to the sail drive. Check the sail
drive model and serial number.
Figure 9
129670-07202
Continuous power kW
Speed of prop.shaft
Gear Model
ｍｉｎ
-１
Fuel stop power kW
MFG.DATE
ｍｉｎ
-１
/
/
ｍｉｎ
-１
Model
ENG.No.
/
㻹㻻㻰㻱㻸
㻹㻲㻳㻚㻌㻺㻻㻚
㻳㻱㻭㻾㻌㻾㻭㼀㻵㻻
㻻㻵㻸㻌
177524-02903
196460-02120
MADE IN EU
MODEL
P/N
GEAR RATIO
MFG.NO.
OIL TYPE
