Yanmar 4JH45 - Checking and Adding Coolant

BEFORE YOU OPERATE
56 JH Series Operation Manual
Checking and Adding Coolant
3JH40
Figure 8
1 – Coolant drain cock
(Cylinderblock)
Figure 1
Figure 9
2 – Coolant pump
3 – Coolant tank (Heat exchanger)
4 – Coolant drain cock
(Coolant tank/Heat exchanger)
5 – Seawater pump
(Drain from pump cover)
1
108119-01X01
234
5
108120-01X01
