2 Spindle Orientation
32 YASKAWA TM.A1000SW.063 Spindle Orientation A1000 Custom Software Supplement
Table 19 Monitor Chinese Display Text
P2-04 Marker Offset 3
零位脉冲偏置 3
P2-05 Marker Offset 4
零位脉冲偏置 4
P2-06 Motor Ratio 1
电机齿轮比 1
P2-07 Motor Ratio 2
电机齿轮比 2
P2-08 Motor Ratio 3
电机齿轮比 3
P2-09
ORT ASR Enable
0: Disabled
1: Enabled
定位 ASR 选择
P2-10 ASR P Gain 3
ASR 比例增益 3
P2-11 ASR I Time 3
ASR 积分时间 3
P2-12 ASR P Gain 4
ASR 比例增益 4
P2-13 ASR I Time 4
ASR 积分时间 4
S High Frequency
高频
S1 HighFreq Control
高频控制
S1-01
OnDelay Comp Sel
0: Disabled
1: Enabled
延迟补偿选择
0: 无效
1: 有效
S1-03
Extend I Sample
0: Disabled
1: Enabled
扩展电流采样模式
0: 无效
1: 有效
S2 Ctrl Mode Switch
控制模式切换
S2-01 HF SwOver Freq
控制模式切换频率
S2-02 HF CtrlMode SwBW
控制模式切换频幅
S2-05 HF SlipComp Gain
滑差补偿增益
S2-06 HF SlipComp Time
滑差补偿延迟时间
S2-07 HF SlipComp Lim
滑差补偿极限
S2-08
HF SlipCompRegen
0: Disabled
1: Above 6 Hz
2: Lowst possbl spd
再生滑差补偿
0: 再生滑差补偿无效
1: 有效 6Hz 以上
2: 有效 全范围
S2-11 HF SwOver Freq 2
模式切换频率 2
S2-12 HF CtrlModeSwBW2
模式切换频幅 2
S2-15 HF SlipCompGain2
滑差补偿增益 2
S2-16 HF SlipCompTime2
滑差补偿延迟 2
S2-17 HF SlipComp Lim2
滑差补偿极限 2
S2-18
HF SlipCompRgn 2
0: Disabled
1: Above 6 Hz
2: Lowst possbl spd
再生滑差补偿 2
0: 再生滑差补偿无效
1: 有效 6Hz 以上
2: 有效 全范围
Monitor No. English Display Text Chinese Display Text
U7 Spindle Orient
主轴定位监视
U7-02 Dist From Marker
零位脉冲偏移距离
U7-03 Dist From Offset
零位脉冲偏置距离
U7-02/03
Alternate
Looking for C/Z
搜索零位脉冲
U7-02/03
Alternate
PG Freq Limit
编码器频率限制
U7-04 Commanded Offset
指令偏置
Parameter No. English Display Text Chinese Display Text

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
