YASKAWA A1000 Manual

2 Spindle Orientation
YASKAWA TM.A1000SW.063 Spindle Orientation A1000 Custom Software Supplement 33
Table 20 Multi-Function Input Chinese Text
Table 21 Multi-Function Output Chinese Text
Table 22 Fault and Alarm Chinese Text
U7-05 Sequence Step
顺控步骤
U7-06 Serial Offset
串行偏置
Setting English Display Text Chinese Display
50h Mode Switch Prev
控制模式切换选择
80h Orient CMD
定位指令
81h Orient CMD FWD
正转定位指令
82h Orient CMD REV
反转定位指令
83h Sequential Reset
顺控复位
84h Offset Sel 1
零位偏置选择 1
85h Offset Sel 2
零位偏置选择 2
86h Gear Ratio Sel 1
电机齿轮比选择 1
87h Gear Ratio Sel 2
电机齿轮比选择 2
Setting English Display Text Chinese Display Text
40h Orient Complete
定位完了
41h Home Position
原点位置
Fault or Alarm English Display Text Chinese Display Text
CDEV Marker Det Error
零位脉冲检测错误
OPE12 Orient Param Err
定位参数错误
OPE21 Switch Freq Err
切换频率错误
Monitor No. English Display Text Chinese Display Text

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
