User Constant Tables
5-41
Digital Reference Board: F3
User constants for the Digital Reference Board are shown in the following table.
Con-
stant
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO
BUS
Regis-
ter
Page
V/f
V/f
with
PG
Open
Loop
Vec-
tor
Flux
Vec-
tor
F3-01
Digital
input option
Sets the Digital Reference
Board input method.
0: BCD 1% unit
1: BCD 0.1% unit
2: BCD 0.01% unit
3: BCD 1 Hz unit
4: BCD 0.1 Hz unit
5: BCD 0.01 Hz unit
6: BCD special setting (5-
digit input)
7: Binary input
6 is only effective when the
DI-16H2 is used.
When o1-03 is set to 2 or
higher, the input will be
BCD, and the units will
change to the o1-03 setting.
0 to 7 0 No A A A A 390H 6-164
