Drive Parameter Listing
(n070-n079) Section 8
PARA- SETTING RANGE SETTING FACTORY USER PARA.
METER NAME (AND UNITS) INCREMENT SETTING SETTING REF.
Analog Frequency Reference
n070
Filter Time Constant 0.00 to 2.00 0.01 s 0.10
(CN2, Voltage Ref Input)
n071
Analog Frequency Reference
-255 to 255 1% 100
Gain (CN2, Current Ref Input)
n072
Analog Frequency Reference
-100 to 100 1% 0
5.32
Bias (CN2, Current Ref Input)
Analog Frequency Reference
n073
Filter Time Constant 0.00 to 2.00 0.01 s 0.10
(CN2, Current Ref Input)
n074
Pulse Train Frequency
-255 to 255 1% 100
Reference Gain
n075
Pulse Train Frequency
-100 to 100 1% 0 5.11
Reference Bias
n076
Pulse Train Frequency Ref-
0.00 to 2.00 0.01 s 0.10
erence Filter Time Constant
0: Multi-Function analog input disabled
1: Aux. Frequency reference
n077 Multi-Function Analog
2: Frequency gain 01
Input Selection
3: Frequency bias
4: Voltage bias
n078
Multi-Function Analog Input 0: 0 - 10V
10
5.32
Signal Selection 1: 4 - 20 mA
n079
Multi-Function Analog Input
0 to 50 1% 10
Bias Setting
Drive Parameters - Continued
42
