Drive Parameter Listing
(n096-n109) Section 8
PARA- SETTING RANGE SETTING FACTORY USER PARA.
METER NAME (AND UNITS) INCREMENT SETTING SETTING REF.
0: Detection Disabled
1: Detect only at set frequency;
operation continues
2: Detect only at set frequency;
n096 Overtorque Detection (OL3) coast to stop 1 0
3: Detect during all frequency conditions;
operation continues
4: Detect during all frequency conditions;
coast to stop 5.20
Overtorque Detection
n097 Selection (OL3)
0: Detected by output torque
10
(Note 5)
1: Detected by output current
n098
Overtorque Detection
Level (OL3)
30 to 200 1 (%) 160
n099
Overtorque Detection
Delay Time (OL3)
0.1 to 10.0 0.1 (sec)
0.1 (sec)
0.1 (sec)
0.1
n100
Up/Down Hold 0: Disabled
Memory 1: Enabled
10 5.10
n101
Speed Search
Deceleration Time
0.0 to 10.0 2 5.18
n102
Speed Search Operation
Level
0 to 200% 1 (%) 150 5.18
n103
Torque Compensation Gain
0.0 to 2.5 0.1 1.0
(Note 4)
n104
To rque Compensation
5.26
Time Constant
0.0 to 25.5 (Note 2)
n105
To rque Compensation 0.1 (W) or
Iron Loss
0.0 to 6550
1 (W)
(Note 1)
n106 Motor Rated Slip (Note 4) 0.0 to 20.0 0.1 (Hz) (Note 1) 2.2, 5.22
n107
Motor Line-to-line
0.001 (ohm)
Resistance
0.000 to 65.50 (Note 1)
n108
Motor Leakage 0.01 (mH)
Inductance (Note 1)
0.00 to 655.0
or 0.1 (mH)
(Note 1)
n109
To rque Compensation
1 (%)
Limit (Note 5)
0 to 250 150 5.26
Drive Parameters - Continued
44
