3.2 Operations
3-85
9
head1
3
Utility Function Mode
For Fine-tuning After Adjusting the Anti-Resonance Control
Step Display after Operation Keys Operation
1
Press the Key to view the main
menu for the utility function mode.
Use the
or Key to move
through the list, select Fn204.
2
Press the
Key to display the “Tun-
ing Mode = 1” as shown on the left.
3
Press the
Key while “Tuning Mode
= 1” is displayed. The screen shown on the
left will appear and “damp” will flash.
4
Select the digit with the or
Key, and press the or Key to
set the damping gain.
Note: Increase the damping gain from
about 0% to 200% in 10% incre-
ments while checking the effect of
vibration reduction. If vibration
reduction is still insufficient at a
gain of 200%, cancel the setting,
and lower the control gain by using
a different method, such as one-
parameter tuning.
5
If fine tuning of the frequency is necessary,
press the
Key. The cursor will move
from “damp” to “freq.” If fine-tuning is not
necessary, skip step 6 and go to step 7.
6
Select the digit with the or
Key, and press the or Key to
fine-tune the frequency.
7
Press the
Key to save the settings.
“DONE” will flash for approximately two
seconds and “RUN” will be displayed.
㧾㨁㧺 㧲㨁㧺㧯㨀㧵㧻㧺
㧲㨚㧞㧜㧟㧦㧻㨚㨑㧼㨞㨙㨀㨡㨚
㧲㨚㧞㧜㧠㧦㧭㨂㨕㨎ޓ㧿㨡㨜
㧲㨚㧞㧜㧡㧦㨂㨕㨎ޓ㧿㨡㨜
㧲㨚㧞㧜㧢㧦㧱㨍㨟㨥ޓ㧲㧲㨀
㧾㨁㧺㧲㨁㧺㧯㨀㧵㧻㧺
㨀㨡㨚㨕㨚㨓㧹㨛㨐㨑㧩㧝
㧾㨁㧺㨂㨕㨎㧿㨡㨜
㨒㨞㨑㨝㧩㧜㧠㧜㧜㧴㨦
㨐㨍㨙㨜㧩㧜㧝㧞㧜
㧾㨁㧺㨂㨕㨎㧿㨡㨜
㨒㨞㨑㨝㧩㧜㧠㧜㧜㧴㨦
㨐㨍㨙㨜㧩㧜㧝㧡㧜
㧾㨁㧺㨂㨕㨎㧿㨡㨜
㨒㨞㨑㨝㧩㧜㧠㧜㧜㧴㨦
㨐㨍㨙㨜㧩㧜㧝㧡㧜
㧾㨁㧺㨂㨕㨎㧿㨡㨜
㨒㨞㨑㨝㧩㧜㧠㧞㧜㧴㨦
㨐㨍㨙㨜㧩㧜㧝㧡㧜
㧾㨁㧺 㨂㨕㨎㧿㨡㨜
㨒㨞㨑㨝㧩㧜㧠㧞㧜㧴㨦
㨐㨍㨙㨜㧩㧜㧝㧡㧜
To Next Page
