3 Utility Function Mode
3.2.8 Automatic Tuning of Analog (Speed, Torque) Reference Offset (Fn009)
3-22
3.2.8 Automatic Tuning of Analog (Speed, Torque) Reference Offset
(Fn009)
This function measures the amount of offsets and adjusts the reference voltage auto-
matically. The amount of offsets measured is saved in the SERVOPACK.
Note: This function cannot be used when a position loop has been formed with a host control-
ler. Use the manual servo turning of speed reference offset (Fn00A) function or the man-
ual servo turning of torque reference offset (Fn00B) function to adjust the reference
voltage.
(1) Preparation
The following conditions must be met to adjust the offsets of speed or torque analog
reference automatically.
• The write prohibited setting (Fn010) must not be set to write-protect parameters.
• The servomotor power must be OFF.
(2) Operating Procedure
Use the following procedure.
Step Display after Operation Keys Operation
1 Set the analog voltage input to 0 V.
2
Press the Key to view the main
menu of the utility function mode. Use
the
or Key to move
through the list and select Fn009.
3
Press the
Key. The display
changes to the Fn009 execution dis-
play.
Un000=0 00000
Un002=0 00000
Un008=0 0000000000
Un00D=0 0000000000
BB − PRM/MON−
BB
− FUNCTION−
Fn008:Mturn Clr
Fn009:Ref Adj
Fn00A:Vel Adj
Fn00B:Trq Adj
BB
Ref Adjus t
S t a rt : [DA T A ]
Return: [SET]
To Next Page
