3.2 Operations
3-89
9
head1
3
Utility Function Mode
4
Press the
Key. The displayed “Mea-
sure f” value will be displayed as the “Setting
f” value as well.
Example of measured waveform
5
If the vibration is not completely suppressed,
select the digit with the or Key,
and press the or Key to fine-
tune the frequency “setting f.” Skip this step
and go to step 7 if the fine-tuning of the fre-
quency is not necessary.
Note: If the setting frequency and actual
operating frequency are different, “Set-
ting” will flash.
6
Press the
Key. The “Setting f” will
change to usual display and the frequency cur-
rently displayed will be set for the vibration
suppression function
.
Example of measured waveform
(cont’d)
Step Display after Operation Keys Operation
㧾㨁㧺㨂㨕㨎㧿㨡㨜
㧹㨑㨍㨟㨡㨞㨑㨒㧩㧜㧝㧜㧚㧠㧴㨦
㧿㨑㨠㨠㨕㨚㨓㨒㧩㧜㧝㧜㧚㧠㧴㨦
Position
Error
Torque
reference
㧾㨁㧺㨂㨕㨎㧿㨡㨜
㧹㨑㨍㨟㨡㨞㨑㨒㧩㧜㧝㧜㧚㧠㧴㨦
㧿㨑㨠㨠㨕㨚㨓㨒㧩㧜㧝㧞㧚㧠㧴㨦
㧾㨁㧺㨂㨕㨎㧿㨡㨜
㧹㨑㨍㨟㨡㨞㨑㨒㧩㧜㧝㧜㧚㧠㧴㨦
㧿㨑㨠㨠㨕㨚㨓㨒㧩㧜㧝㧞㧚㧠㧴㨦
Position
Error
Torque
reference
To Next Page
