YASKAWA E-7 Series User Manual

3 Utility Function Mode
3.2.32 EasyFFT (Fn206)
3-92
2
Press the
Key. The display changes
to the Fn206 execution display.
Note: If the display is not switched and
“NO-OP” is displayed in the status
display, check to make sure that the
required operating conditions are
being met ((1) Preparation) and
take corrective action.
3
The cursor is on the setting of “Input.”
Press the or Key to set the
sweep torque reference amplitude (Pn456)
Setting range: 1 to 800.
Note: When making the initial settings for
EasyFFT, do not change the setting
for the reference amplitude. Start
with the original value of 15.
Increasing reference amplitude
increases the detection accuracy, but
the vibration and noise from the
machine will increase. Increase the
amplitude value little by little.
4
Press the Key to turn the servomotor
power ON. The display “BB” and “Set-
ting” changes to “RUN” and “Ready.”
5
Press the (forward run start) Key or
(reverse run start) Key to run the
servomotor and start the frequency mea-
surement. “Measure” is displayed during
the measurement.
Within a quarter turn, the servomotor will
move forward and then in reverse several
times.
Note:
• Press the Key to cancel the mea-
surement. The servomotor stops moving
and the power turns OFF. The detection
of the resonance frequency is not com-
pleted.
• The actions of the servomotor are very
minute in this operation. Also at the
same time, the servomotor emits a noise.
To ensure safety, do not enter the work-
ing envelope of the motor.
(cont’d)
Step Display after Operation Keys Operation
㧮㧮ޓޓޓޓޓ㧙㧱㨍㨟㨥ޓ㧲㧲㨀㧙
㧿㨑㨠㨠㨕㨚㨓
㧵㨚㨜㨡㨠ޓ㧩ޓ㧜㧝㧡㧑
㧮㧮ޓޓޓޓޓ㧙㧱㨍㨟㨥ޓ㧲㧲㨀㧙
㧿㨑㨠㨠㨕㨚㨓
㧵㨚㨜㨡㨠ޓ㧩ޓ㧜㧝㧡㧑
㧾㨁㧺ޓޓޓޓ㧙㧱㨍㨟㨥ޓ㧲㧲㨀㧙
㧾㨑㨍㨐㨥
㧵㨚㨜㨡㨠ޓ㧩ޓ㧜㧝㧡㧑
㧹㨑㨍㨟㨡㨞㨑
㧵㨚㨜㨡㨠ޓ㧩ޓ㧜㧝㧡㧑
㧾㨁㧺ޓޓޓޓ㧙㧱㨍㨟㨥ޓ㧲㧲㨀㧙
