YASKAWA E-7 Series User Manual

4 Parameter Copy Mode
4.2.3 Verify Parameters (VERIFY)
4-10
6
When the verification of the parameters
read out from the digital operator, the
parameters read out from the SERVO-
PACK, and the verification is completed,
“Completed” is displayed.
7
The verification result is displayed.
If any unmatched parameters were
found, these unmatched parameter num-
bers are displayed in a list. Press the
or Key to scroll the screen
to display all the unmatched parameter
numbers. (five numbers can be displayed
at once.)
Pn
∗∗∗
among the displayed unmatched
parameters are the reserved parameters
for the SERVOPACK.
8
Press the Key.
The parameter block selection display
appears.
9
Press the
Key.
The display returns to the parameter copy
mode menu display.
(cont’d)
Step Display after Operation Keys Operation
00:SGDV− R70
Completed
BB − VERIFY−
All Parameters
are matched
BB − VERIFY−
When all parameters are matched.
Pn001
Pn202
Pn100 Unmatched
Pn101 Parameters
BB − VERIFY−
When unmatched parameters are found.
00:SGDV− R70
01:∗∗∗∗
02:∗∗∗∗
03:∗∗∗∗
BB − VERIFY−
1:SERVO→ OP
2:OP→ SERVO
3:VERIFY
4:LIST
BB − COPY−
