1 Introduction
1-2
The JUSP-OP05A-1-E optional digital operator for the
Σ
-V Series SGDV
SERVOPACK is used to set and display the SERVOPACK parameters.
Connect the digital operator to the CN3 connector of the SERVOPACK.
Note: JUSP-OP05A digital operators are used with Σ-III SERVOPACKs. A special connector
(JZSP-CVS05-A3-E) is required to use these operators with Σ-V SERVOPACKs. For
details, refer to
Σ -V Series User’s Manual, Setup, Rotational Motor (Manual No.: SIEP
S800000 43).
Insert securely to the CN3 connector of the SERVOPACK
SGDV SERVOPACK
JUSP-OP05A-1-E
Digital Operator
VCMP
SVON C OIN TGON REF
CHARGE
ALARM
DATA
JOG
SVON
SCROLL MODE/SET
RESET
SERVO
READ WRITE
SERVO
YASKAWA
DIGITAL OPERATOR JUSP-OP05A-1-E
