YASKAWA E-7 Series User Manual

2 Parameter/Monitor Modes
2.2.1 Monitor Items
2-8
∗1. The input signal monitor Un005 is displayed as follows. The upper portion indicates the
OFF status, the lower portion indicates the ON status. The undefined digits are displayed
in the lower portion (ON status).
Un015
Safety input/output signal monitor
*3
−
Un020 Motor rated speed
min
-1
Un021 Motor maximum speed
min
-1
Un084
Linear scale pitch
(Scale pitch=Un084×10
Un085
[pm])
−
Un085
Linear scale pitch index
(Scale pitch=Un084×10
Un085
[pm])
−
Parameter No Content of Display Unit
Display
LED
Number
Input Terminal Name Signal Name (Factory Setting)
1 CN1-40 (can be allocated) /S-ON (Servo ON) input
2 CN1-41 (can be allocated)
/P-CON (Proportional operation refer-
ence) input
3 CN1-42 (can be allocated) P-OT (Forward run prohibited) input
4 CN1-43 (can be allocated) N-OT (Reverse run prohibited) input
5 CN1-44 (can be allocated) /ALM-RST (Alarm reset) input
6 CN1-45 (can be allocated) /P-CL (Forward current limit ON) input
7 CN1-46 (can be allocated) /N-CL (Reverse current limit ON) input
8 CN1-4 (cannot be allocated) SEN (SEN signal) input
Un005=
8 7 6 5 4 3 2 1 digit
