YASKAWA E-7 Series User Manual

3 Utility Function Mode
3.2.4 Program JOG Operation (Fn004)
3-16
6
When the set program JOG operation
movement is completed, “END” is dis-
played for one second, and then
“RUN” is displayed.
Press the Key. The servomotor
becomes baseblocked status. The dis-
play returns to the main menu of the
utility function mode.
7 After program JOG operation, turn OFF the power and then turn ON again.
(cont’d)
Step Display after Operation Keys Operation
㧱㧺㧰ޓޓޓޓޓ㧙㧼㧾㧳ޓ㧶㧻㧳㧙
㧼㨚㧡㧟㧝㧩㧜㧜㧜㧟㧞㧣㧢㧤
㧼㨚㧡㧟㧟㧩㧜㧜㧡㧜㧜
㧼㨚㧡㧟㧠㧩㧜㧜㧝㧜㧜ޓ
㧼㨚㧡㧟㧢㧩㧜㧜㧜㧝㧜

YASKAWA E-7 Series Specifications

General

Type	Servo Drive
Series	E-7 Series
Communication	MECHATROLINK-II, MECHATROLINK-III
Feedback	Incremental encoder, Absolute encoder
Protection Features	Overvoltage protection, Undervoltage protection, Overheat protection, Short circuit protection
