6.3 MEMOBUS/Modbus Communications
240 YASKAWA SIEPC71061753C GA500 Technical Manual
Register No.
(Hex.)
Description
00CC
Minor Fault Description 6
bit 0 Reserved
bit 1 TrPC [IGBT Maintenance Time (90%)]
bit 2 LT-3 [SoftChargeBypassRelay MainteTime]
bit 3 LT-4 [IGBT Maintenance Time (50%)]
bit 4 boL [Braking Transistor Overload]
bit 5 - 7 Reserved
bit 8 dWAL [DriveWorksEZ Alarm]
bit 9 dWA2 [DriveWorksEZ Alarm 2]
bit A dWA3 [DriveWorksEZ Alarm 3]
bit B - F Reserved
00CD - 00CF Reserved
00D0
CPF Contents 1
bit 0 - 1 Reserved
bit 2 CPF02 [Control Circuit Error]
bit 3 CPF03 [Control Circuit Error]
bit 4 - 5 Reserved
bit 6 CPF06 [Control Circuit Error]
bit 7 Reserved
bit 8 CPF08 [Control Circuit Error]
bit 9 - A Reserved
bit B CPF11 [Control Circuit Error]
bit C CPF12 [Control Circuit Error]
bit D CPF13 [Control Circuit Error]
bit E CPF14 [Control Circuit Error]
bit F Reserved
00D1
CPF Contents 2
bit 0 CPF16 [Control Circuit Error]
bit 1 CPF17 [Control Circuit Error]
bit 2 CPF18 [Control Circuit Error]
bit 3 CPF19 [Control Circuit Error]
bit 4 CPF20 [Control Circuit Error]
bit 5 CPF21 [Control Circuit Error]
bit 6 CPF22 [Control Circuit Error]
bit 7 CPF23 [Control Circuit Error]
bit 8 CPF24 [Control Circuit Error]
bit 9 - F Reserved
00D2
CPF Contents 3
bit 0- 5 Reserved
bit 6
CPF38 [Control Circuit Error]
bit 7 - F Reserved
00D3 - 00D7 Reserved
