12.7 F: Options
620 YASKAWA SIEPC71061753C GA500 Technical Manual
■ F7-10: Gateway Address 2
No.
(Hex.)
Name Description
Default
(Range)
F7-10
(03EE)
Gateway Address 2
Sets the second octet of the gateway address of the connected network.
168
(0 - 255)
Note:
Set this parameter when F7-13 = 0 [Address Mode at Startup = Static].
■ F7-11: Gateway Address 3
No.
(Hex.)
Name Description
Default
(Range)
F7-11
(03EF)
Gateway Address 3
Sets the third octet of the gateway address of the connected network.
1
(0 - 255)
Note:
Set this parameter when F7-13 = 0 [Address Mode at Startup = Static].
■ F7-12: Gateway Address 4
No.
(Hex.)
Name Description
Default
(Range)
F7-12
(03F0)
Gateway Address 4
Sets the fourth octet of the gateway address of the connected network.
1
(0 - 255)
Note:
Set this parameter when F7-13 = 0 [Address Mode at Startup = Static].
■ F7-13: Address Mode at Startup
No.
(Hex.)
Name Description
Default
(Range)
F7-13
(03F1)
Address Mode at Startup
Sets the method to set option card IP addresses.
2
(0 - 2)
0 : Static
1 : BOOTP
2 : DHCP
Note:
• The following setting values are available when using the PROFINET communication option card (SI-EP3).
–0: Static
–2: DCP
• When F7-13 = 0, set parameters F7-01 to F7-12 [IP Address 1 to Gateway Address 4] to set the IP Address. Be sure to set a different
IP address for each drive on the network.
■ F7-14: Duplex Mode Selection
No.
(Hex.)
Name Description
Default
(Range)
F7-14
(03F2)
Duplex Mode Selection
Sets the duplex mode setting method.
1
(0 - 8)
0 : Half/Half
1 : Auto/Auto
2 : Full/Full
3 : Half/Auto
Port 1 is set to “Half” and port 2 is set to “Auto”.
4 : Half/Full
Port 1 is set to “Half” and port 2 is set to “Full”.
5 : Auto/Half
Port 1 is set to “Auto” and port 2 is set to “Half”.
6 : Auto/Full
