12.8 H: Terminal Function Selection
630 YASKAWA SIEPC71061753C GA500 Technical Manual
■ 2: External Reference 1/2 Selection
Setting Value Function Description
2 External Reference 1/2
Selection
Sets the drive to use Run command source 1/2 or Reference command source 1/2 when in REMOTE Mode.
Note:
The ability to switch the Run command source and frequency reference source depends on the setting of b1-07 [LOCAL/REMOTE Run
Selection].
Table 12.55 Ability to Switch the Run Command Source and Frequency Reference Source when Inputting the Run
Command
b1-07 Run command source Frequency reference source
0 [Disregard Existing RUN Command] (Default) No Yes
1 [Accept Existing RUN Command] Yes Yes
ON : b1-15 [Frequency Reference Selection 2], b1-16 [Run Command Selection 2]
OFF : b1-01 [Frequency Reference Selection 1], b1-02 [Run Command Selection 1]
■ 3: Multi-Step Speed Reference 1
Setting Value Function Description
3 Multi-Step Speed Reference
1
Uses speed references d1-01 to d1-16 to set a multi-step speed reference.
Note:
Refer to Setting Procedures for Multi-step Speed Operation on page 566 for more information.
■ 4: Multi-Step Speed Reference 2
Setting Value Function Description
4 Multi-Step Speed Reference
2
Uses speed references d1-01 to d1-16 to set a multi-step speed reference.
Note:
Refer to Setting Procedures for Multi-step Speed Operation on page 566 for more information.
■ 5: Multi-Step Speed Reference 3
Setting Value Function Description
5 Multi-Step Speed Reference
3
Uses speed references d1-01 to d1-16 to set a multi-step speed reference.
Note:
Refer to Setting Procedures for Multi-step Speed Operation on page 566 for more information.
■ 6: Jog Reference Selection
Setting Value Function Description
6 Jog Reference Selection
Sets the drive to use the JOG Frequency Reference (JOG command) set in d1-17. The JOG Frequency Reference (JOG
command) overrides Frequency References 1 to 16 (d1-01 to d1-16).
■ 7: Accel/Decel Time Selection 1
Setting Value Function Description
7 Accel/Decel Time Selection
1
Sets the drive to use Acceleration/Deceleration Time 1 [C1-01, C1-02] or Acceleration/Deceleration Time 2 [C1-03, C1-04].
Note:
Refer to C1: Accel & Decel Time on page 546 for more information.
■ 8: Baseblock Command (N.O.)
Setting Value Function Description
8 Baseblock Command (N.
O.)
Sets the command that stops drive output and coasts the motor to stop when the input is ON.
