YASKAWA GA50U Series User Manual

3 Drive Specifications
10 YASKAWA TOEPC71061752B GA500 Drive Installation & Primary Operation
Item Specification
Altitude
1000 m (3281 ft) Maximum
Note:
Derate the output current by 1% for each 100 m (328 ft) to install the drive in altitudes between
1000 m to 4000 m (3281 ft to 13123 ft).
It is not necessary to derate the rated voltage in these conditions:
• Installing the drive at 2000 m (6562 ft) or lower
• Installing the drive between 2000 m to 4000 m (6562 ft to 13123 ft) and grounding the neutral
point on the power supply.
Contact Yaskawa or your nearest sales representative when not grounding the neutral point.
Vibration
• 10 Hz to 20 Hz: 1 G (9.8 m/s
2
, 32.15 ft/s
2
)
• 20 Hz to 55 Hz: 0.6 G (5.9 m/s
2
, 19.36 ft/s
2
)
Installation
Orientation
Install the drive vertically for sufficient airflow to cool the drive.
Table 3.2 Standard
Item Specification
Harmonized
Standard
• UL 61800-5-1
• EN 61800-3
• EN 61800-5-1
• Two Safe Disable inputs and one EDM output according to EN ISO 13849-1 (Cat.3, PL e), EN
61800-5-2 SIL3
Protection design
IP20/UL Open Type
IP20/UL Type 1
Note:
Install a UL Type 1 kit (optional) on an IP20/UL Open Type drive to change the drive to an IP20/
UL Type 1 enclosure.
Table 3.3 Protection Functions
Item Specification
Motor Protection
Electronic thermal overload protection
Momentary
Overcurrent
Protection
Drive stops when the output current is more than 200% of the HD output current.
Overload
Protection
Drive stops when the output current is more than these overload tolerances:
• HD: 150% of the rated output current for 60 seconds.
• ND: 110% of the rated output current for 60 seconds.
Note:
If output frequency < 6 Hz, the drive can trigger the overload protection function when the output
current is in the overload tolerance range.
Overvoltage
Protection
200 V class: Stops when the DC bus voltage is more than approximately 410 V
400 V class: Stops when the DC bus voltage is more than approximately 820 V
Undervoltage
Protection
Single-phase 200 V class: Stops when the DC bus voltage decreases to less than approximately 160 V
Three-phase 200 V class: Stops when the DC bus voltage decreases to less than approximately 190 V
Three-phase 400 V class: Stops when the DC bus voltage decreases to less than approximately 380 V
