Three-Phase 200 V Class
Model Terminal
Recomm.
Gauge
mm
2
Applicable
Gauge
mm
2
Wire
Stripping
Length
*1
mm
Terminal Screw
Tightening
Torque
N∙m (in∙lb)
Size Shape
2001
R/L1, S/L2, T/L3 2.5 2.5 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2.5 2.5 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1, +2 2.5 2.5 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2.5 2.5 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
2.5
*2
2.5
*2
- M3.5
0.8 - 1.0
(7.1 - 8.9)
2002
R/L1, S/L2, T/L3 2.5 2.5 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2.5 2.5 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1, +2 2.5 2.5 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2.5 2.5 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
2.5
*2
2.5
*2
- M3.5
0.8 - 1.0
(7.1 - 8.9)
2004
R/L1, S/L2, T/L3 2.5 2.5 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2.5 2.5 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1, +2 2.5 2.5 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2.5 2.5 6.5 M3
0.5 - 0.6
(4.4 - 5.3)
2.5
*2
2.5
*2
- M3.5
0.8 - 1.0
(7.1 - 8.9)
