3.3 Message Communication Error
3.3.3 Checking the Message Function
3-22
[ b ] When using the message receive function (MSG-RCV)
• Parameter list when Pro-Typ (Transmission protocol) is MEMOBUS
* IN: Input parameter, OUT: Output parameter
Note: For the checking details of parameters No. 04 to 11, refer to Appendix G MSG-SND/MSG-RCV
Functions of Machine Controller MP2310 Basic Module Users Manual (manual No.: SIEP C880732
01).
Parameter list when Pro-Typ (Transmission protocol) is Non-procedural 1 or Non-procedural 2
* IN: Input parameter, OUT: Output parameter
Parameter
No.
IN/OUT
*
Details Description and Checking Details
02
IN
Connection number
Sets the transmission source to be used at the remote station. (Specify
the connection number in the connection parameters.)
Check that the setting is within the following setting range.
Built-in Ethernet Module: 1 to 4
218IF-02 or 218IF-01 Module: 1 to 20
04
OUT
Function code Outputs the function code requested from the transmission side.
05
OUT
Data address
Outputs the start address of the data requested from the transmission
side.
06
OUT
Data size
Outputs the read symbol write data size requested from the transmis-
sion side.
08
IN
Coil offset Sets the coil’s offset word address.
09
IN
Input relay offset Sets the offset word address of an input relay.
10
IN
Input register offset Sets the offset word address of an input register.
11
IN
Holding register offset Sets the offset word address of a holding register.
Parameter
No.
IN/OUT
*
Details Description and Checking Details
02 IN
Connection number
Sets the transmission source to be used at the remote station. (Specify
the connection number in the connection parameters.)
Check that the setting is within the following setting range.
Built-in Ethernet Module: 1 to 4
218IF-02 or 218IF-01 Module: 1 to 20
04, 05
(unused)
06 OUT
Data size
Outputs the read symbol write data size requested from the transmis-
sion side.
07 to 11
(unused)
12 IN
Register offset Sets the offset word address of a holding register.
