5 Installation Procedure
YASKAWA ELECTRIC TOBP C730600 75B YASKAWA AC Drive Option PG-B3 Installation Manual 21
7. Replace and secure the front covers of the drive (D, F) and replace the digital
operator (E).
NOTICE: Do not pinch cables between the front covers and the drive. Failure to comply could cause
erroneous operation.
Figure 9
Figure 9 Replace the Front Covers and Digital Operator
8. Connect the PG encoder outputs to the option.
D
E
F
TOBP_C730600_75B_1_0_E.book 21 ページ ２０１７年２月１７日 金曜日 午後３時２分
