2.3 Specifications
2-7
I/O Signals
Sequence
Input
Signals
SERVO-
PACKs
Fixed
Input
Signals
Allowable voltage range: 5 VDC ±5%
Number of input points: 1
Input signal: SEN (Absolute Data Request) signal
Input
Signals
for
Which
Alloca-
tions
Can Be
Changed
Number of input points: 1
Input method: Line driver or open collector
Input Signals
/DEC (Homing Deceleration Switch) signal
/RGRT (Registration Input) signal
CLR (Clear) signal
Allowable voltage range: 24 VDC ±20%
Number of input points: 7
Input method: Sink inputs or source inputs
Input Signals
/S-ON (Servo ON) signal
/P-CON (Proportional Control) signal
P-OT (Forward Drive Prohibit) and N-OT (Reverse Drive
Prohibit) signals
/ALM-RST (Alarm Reset) signal
/P-CL (Forward External Torque Limit) and /N-CL (Reverse
External Torque Limit) signals
/SPD-D (Motor Direction) signal
/SPD-A and /SPD-B (Internal Set Speed Selection) signals
/C-SEL (Control Selection) signal
/ZCLAMP (Zero Clamping) signal
/INHIBIT (Reference Pulse Inhibit) signal
/P-DET (Polarity Detection) signal
/G-SEL (Gain Selection) signal
/PSEL (Reference Pulse Input Multiplication Switch) signal
SEN (Absolute Data Request) signal
/DEC (Homing Deceleration Switch) signal
/MODE 0/1 (Mode Switch Input) signal
/START-STOP (Program Table Operation Start-Stop Input)
signal
/JOGP (Forward Jog Input) signal
/JOGN (Reverse Jog Input) signal
/HOME (Homing Input) signal
/PGMRES (Program Table Operation Reset Input) signal
/SEL0 (Program Step Selection Input 0) signal
/SEL1 (Program Step Selection Input 1) signal
/SEL2 (Program Step Selection Input 2) signal
/SEL3 (Program Step Selection Input 3) signal
/SEL4 (Program Step Selection Input 4) signal
/JOG0 (Jog Speed Table Selection Input 0) signal
/JOG1 (Jog Speed Table Selection Input 1) signal
/JOG2 (Jog Speed Table Selection Input 2) signal
A si
gnal can be allocated and the positive and negative logic
can be changed.
Continued on next page.
