2 Overview
12 YASKAWA ELECTRIC TOBP C730600 89D YASKAWA AC Drive Option SI-EP3 Installation Manual
u Install the Option on a GA500 Drive
An option card installation case is necessary to install the option on a GA500 drive.
The option card installation case model is: JOHB-GA500. This case is sold separately.
Refer to the option card installation case manual for more information about installation.
Figure 1
Figure 1 Option Card Installation Case
Option card installation case
components (sold separately)
Option card
Drive front cover
