6 Related Drive Parameters
6 Related Drive Parameters
The parameters in Table 7 set the drive for operation with the option. Confirm proper setting
of all parameters in Table 7 before starting network communications. Refer to the manual
packaged with the drive for details on setting parameters.
Note: Hex.: MEMOBUS addresses that you can use to change parameters over network
communication are represented in hexadecimal numbers.
Table 7 Related Parameter Settings
No.
(Hex.)
Name Description Values
b1-01
(0180)
<1>
Reference 1 Source
Selects the input method for frequency reference.
0: Keypad
1: Analog Input
2: Memobus/Modbus Communications
3: Option PCB
4: Pulse Train Input
Default: 1
Range: 0 to 4
(Set to 3)
b1-02
(0181)
<1>
Run Command 1 Source
Selects the input method for the Run command.
0: Keypad
1: Digital Input
2: Memobus/Modbus Communications
3: Option PCB
Default: 1
Range: 0 to 3
(Set to 3)
F6-01
(03A2)
Communication Error
Selection
Selects drive response when a bUS error is detected
during communications with the option.
0: Ramp to Stop
1: Coast to Stop
2: Fast Stop (Use C1-09)
3: Alarm Only
<2>
4: Alarm - Run at d1-04 <2> <3>
5: Alarm - Ramp to Stop <3>
Default: 1
Range: 0 to 5
<4>
F6-02
(03A3)
Comm External Fault
(EF0) Detect
Selects the condition for external fault detection (EF0).
0: Always detected
1: Detection during run only
Default: 0
Range: 0, 1
F6-03
(03A4)
Comm External Fault
(EF0) Select
Selects drive response for external fault input (EF0)
detection during option communications.
0: Ramp to Stop
1: Coast to Stop
2: Fast Stop (Use C1-09)
3: Alarm Only
<2>
Default: 1
Range: 0 to 3
F6-06
(03A7)
<5>
Torque Reference/Limit by
Comm
Enabling this parameter allows d5-01 to determine
whether the value is read as the Torque Limit value
(d5-01 = 0) or the Torque Reference value (d5-01 = 1).
0: Disabled
1: Enabled
<6>
Default: 0
Range: 0, 1
F6-07
(03A8)
MultiStep Ref Priority
Select
0: MultiStep References Disabled
1: MultiStep References Enabled
Default: 0 <7>
Range: 0, 1
