MHTH Postioner
SIGMA V
1 Introduction
1.2 Overview
Table 1-2: MHTH 605 Drive Module Specifications
Axis Type Rotation
Rated Load kgf 605
Max MHTH Load @ CG Off Center kgf @ mm 1717 @ 50
Headstock Speed rpm 18.8
180 Degree Sweep Time sec 2.09
Rated CG Off Center mm 152
Rated CG Overhang mm 1375
Load @ 500 mm CG Overhang kgf 1578
Rated Intertia kg*m2 208
Rated Holding Torque Nm 842
Rated Weld Current 
(STD Optional)
Amps 1200/1600
Allowable Thrust kgf 800
Motor Power kW 1.3
* Motor PN, YEC SGMRV-13ANA-YR11
* Motor Speed rpm 3800
* Rated Acceleration Time sec 0.5
Motor PN, Yaskawa Motoman 156009-3
* Total Reduction Ratio R 202
Repeatability mm/mm 0.000028
E-Stop Response sec 0.449
E-Stop Response deg 12.8
**In Position Maximum Motion deg 15.47
Face Plate Through Hole mm 110
Drive Assy Weight kgf/lbs 293/645
** The ‘In Position Maximum Motion’ is the maximum motion expected if the
c
ycle start command is given while the safety zone is violated. This assumes
utilizing the position switches in the safety circuit, and includes the motion
required to clear the switch actuators and implement an E-Stop
12/28

YASKAWA SIGMA 5 Specifications

General

Type	Servo Amplifier
Rated Output Power	50 W to 15 kW
Humidity	90% RH or less (non-condensing)
Communication Interface	MECHATROLINK-II, MECHATROLINK-III, EtherCAT
Feedback	Incremental Encoder, Absolute Encoder
Series	SIGMA-5
Feedback Resolution	20-bit
Protection Functions	Overvoltage, Overcurrent, Overload
Ambient Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 85°C
Vibration Resistance	5.9 m/s² (0.6G)
