YASKAWA SIGMA 5 - Page 26

A-4
163475-1CD
163475-1CD
MHTH Postioner
SIGMA V
Appendix A Illustrated Parts List
A.2 Parts List
15 163410-1 SWITCH KIT, LIMIT, MHTH DRIVE ASSY, ONLY USED
ON THE DX100
1
16 151334-1 GEAR, INPUT, MAIN DRIVE 1
17 151336-1 PLATE, MTG, MAIN DRIVE 1
18 151335-1 GUARD, UPPER, LH, MAIN DRIVE 1
19 151344-1 GUARD, LOWER 1
20 151335-1 GUARD, UPPER, LH, MAIN DRIVE 1
21 149018-1 BEARING, SLEWING, 60T 1
22 151339-1 POST MTG, GROUNDING PLATE, MHTH 1
23 151337-1 PLATE, FACE, MTG MHTH 1
24 145896-2 PIN, HOMING 1
Table A-1: MHTH Parts List
Item Number P/N Description Qty
26/28
