User Constant Tables
5-35
* 1. The factory settings depend on the Inverter capacity. The values for a 200 V Class Inverter of 0.4 kW are given.
* 2. The setting range is 10% to 200% of the Inverter's rated output current. The value for a 200 V Class Inverter of 0.4 kW is given.
* 3. The setting range depends on the Inverter capacity. The value for a 200 V Class Inverter of 0.4 kW is given.
* 4. The lower limit of E2-08 is the setting value of E2-07.
E2-09
Motor
mechanical
loss
Sets motor mechanical loss
as a percentage of motor
rated output (W).
Usually setting is not neces-
sary.
Adjust in the following cir-
cumstances:
• When torque loss is large
due to motor bearing.
• When the torque loss in
the pump or fan is large.
The set mechanical loss will
compensate for torque.
0.0 to
10.0
0.0 No No No No A 316H -
E2-10
Motor iron
loss for
torque com-
pensation
Sets motor iron loss in W
units.
0 to
65535
14 W
*1
No A A No No 317H 6-120
E2-11
Motor rated
output
Set the rated output of the
motor in units of 0.01 kW.
This constant is automati-
cally set during autotuning.
0.00 to
650.00
0.40
kW
*1
No Q Q Q Q 318H 6-117
Con-
stant
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO
BUS
Regis-
ter
Page
V/f
V/f
with
PG
Open
Loop
Vec-
tor
Flux
Vec-
tor
To Next Page
