5-78
U1-40
Cooling fan
operating
time
Monitors the total operat-
ing time of the cooling fan.
The time can be set in 02-
10.
(Cannot be output.) 1 hr A A A A 68H
U1-44
ASR output
without fil-
ter
Monitors the output from
the speed control loop (i.e.,
the primary filter input
value). 100% is displayed
for rated secondary current
of the motor.
10 V: Rated secondary cur-
rent of motor
(-10 V to 10 V)
0.01
%
No No No A 6BH
U1-45
Feed for-
ward con-
trol output
Monitors the output from
feed forward control. 100%
is displayed for rated sec-
ondary current of the motor.
10 V: Rated secondary cur-
rent of motor
(-10 V to 10 V)
0.01
%
No No No A 6CH
Con-
stant
Number
Name Description
Output Signal Level Dur-
ing Multi-Function Analog
Output
Min.
Unit
Control Methods
MEMO
BUS
Regis-
ter
V/f
V/f
with
PG
Open
Loop
Vec-
tor
Flux
Vec-
tor
To Next Page
