Individual Functions
6-129
d5-06
Speed/torque
control
switching
timer
Set the delay time from input-
ting the multi-function input
“speed/torque control change”
(from On to OFF or OFF to ON)
until the control is actually
changed, in ms units.
This function is enabled when
the multi-function input “speed/
torque control change” is set. In
the speed/torque control switch-
ing timer, the analog inputs hold
the values of when the “speed/
torque control change” changes.
Always be sure to allow time for
this process to finish completely.
0 to
1000
0 ms No No No No A 29FH
H3-04
Signal level
selection (ter-
minal A3)
0: 0 to ±10V
1: 0 to ±10V
0 or 1 0 No A A A A 413H
H3-05
Multi-func-
tion analog
input (termi-
nal A3) func-
tion selection
Select from the functions listed
in the following table. Refer to
the next page.
0 to 1F 1F No A A A A 414H
H3-06
Gain (termi-
nal A3)
Sets the input gain (level) when
10 V is input.
Set according to the 100% value
selected from H3-05.
0.0 to
1000.0
100.0% Ye s A A A A 415H
H3-07
Bias (termi-
nal A3)
Sets the input gain (level) when
0 V is input.
Set according to the 100% value
selected from H3-05.
-100.0
to
+100.0
0.0% Yes A A A A 416H
H3-08
Signal level
selection
(terminal A2)
0: 0 to +10V, with lower limit
1: without lower
limit
2: 4 to 20 mA
Switch current and voltage input
using the switch on the control
panel.
0 to 2 2 NoAAAA417H
H3-09
Multi-func-
tion analog
input
(terminal A2)
function
selection
Select multi-function analog
input function for terminal A2.
Refer to the next table.
0 to 1F 0 No A A A A 418H
H3-10
Gain (termi-
nal A2)
Sets the input gain (level) when
10 V (20 mA) is input.
Set according to the 100% value
for the function set for H3-09.
0.0 to
1000.0
100.0% Yes A A A A 419H
H3-11
Bias (termi-
nal A2)
Sets the input gain (level) when
0 V (4 mA) is input.
Set according to the 100% value
for the function set for H3-09.
-100.0
to
+100.0
0.0% Yes A A A A 41AH
Con-
stant
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO
BUS
Regis-
ter
V/f
V/f
with
PG
Open
Loop
Vec-
tor
Flux
Vec-
tor
0 to ±10V,
