9-6
The following option boards are available
Table 9.5 Option Boards
Type Name
Code Num-
ber
Function
Document
Number
Built-in
(con-
nect to
con-
nector)
Speed
(Fre-
quency)
Refer-
ence
Option
Boards
Analog Ref-
erence Board
AI-14U
73600-
C001X
Enables high-precision, high-resolution setting of analog
speed references.
• Input signal ranges: 0 to 10 V (20 kΩ), 1 channel
4 to 20 mA (250 Ω), 1 channel
• Input resolution: 14-bit (1/16384)
TOE-C736-
30.13
Analog Ref-
erence Board
AI-14B
73600-
C002X
Enables high-precision, high-resolution setting of analog
speed references.
• Input signal ranges: 0 to ±10 V (20 kΩ)
4 to 20 mA (500 Ω), 3 channels
• Input resolution: 13-bit + sign (1/8192)
TOE-C736-
30.14
Digital Refer-
ence Board
DI-08
73600-
C003X
Enables 8-bit digital setting of speed references.
• Input signal: 8-bit binary
2-digit BCD + sign signal + set signal
• Input voltage: +24 V (isolated)
• Input current: 8 mA
TOE-C736-
30.15
Digital Refer-
ence Board
DI-16H2
73600-
C016X
Enables 16-bit digital setting of speed references.
• Input signal: 16-bit binary
4-digit BCD + sign signal + set signal
• Input voltage: +24 V (isolated)
• Input current: 8 mA
With 16-bit/12-bit switch.
TOE-C736-
40.7
Moni-
toring
Option
Boards
Analog Mon-
itor Board
AO-08
73600-
D001X
Converts analog signals to monitor the Inverter's output status
(output frequency, output current, etc.) to absolute values and
outputs them.
• Output resolution: 8 bits (1/256)
• Output voltage: 0 to +10 V (not insulated)
• Output channels: 2 channels
TOE-C736-
30.21
Analog Mon-
itor Board
AO-12
73600-
D002X
Output analog signals to monitor the Inverter's output status
(output frequency, output current, etc.).
• Output resolution: 11 bits (1/2048) + sign
• Output voltage: -10 to +10 V (not insulated)
• Output channels: 2 channels
TOE-C736-
30.22
Digital Out-
put Board
DO-08
73600-
D004X
Outputs isolated digital signals to monitor the Inverters oper-
ating status (alarm signals, zero-speed detection, etc.)
Output form: Photocoupler output, 6 channels
(48 V, 50 mA max.)
Relay contact outputs, 2 channels
(250 VAC: 1 A max., 30VDC: 1 A max.)
TOE-C736-
30.24
2C-Relay
Output Board
DO-02C
73600-
D007X
Provides two multi-function outputs (DPDT relay contacts) in
addition to those provided by the Inverter.
TOE-C736-
40.8
PG
Speed
Con-
trol
Boards
PG-A2
73600-
A012X
Used for V/f with PG control. Speed feedback is performed
using the PG attached to the motor to compensate for speed
fluctuations caused by slipping.
• A-phase pulse (single pulse) input (voltage, complemen-
tary, open-collector input)
• Maximum input frequency: 32767 Hz
• Pulse monitor output: +12 V, 20 mA
(PG power supply output: +12 V, 200 mA max.)
TOE-C736-
40.1
