STANDARD SPECIFICATIONS
Model
6
CH-K100
Capacity
Cooling
High Fire MBTUh
(kW)
1200
(352
)
Low Fire MBTUh
(kW)
840
(246)
Heating
High Fire MBTUh
(kW)
976
(286)
Low Fire MBTUh
(kW)
683
(200)
Capacity Control High Fire (100%) - Low Fire (70%) - Off (0%)
Chilled / Hot Water
Cooling
Inlet °F
(°C)
54.5
(12.5)
Outlet °F
(°C)
44.6
(7.0)
Heating
Inlet °F
(°C)
122.9
(50.5)
Outlet °F
(°C)
131.0
(55.0)
Rated Water Flow GPM
(l/s)
241.9
(15.3)
Evaporator Pressure Loss
3
PSI
(kPa)
14.1
(97.2)
Maximum Operating Pressure
PSI
(kPa)
150.0
(1034)
Water Retention Volume Gal
(l)
81.0
(307)
Cooling Water
Total Heat Rejection MBTUh
(kW)
21
Inlet Temperature °F
(°C)
85.1
(29.5)
Outlet Temperature °F
(°C)
95.9
(35.5)
Rated Water Flow GPM
(l/s)
402.5
(25.4)
Condenser + Absorber Pressure Loss
PSI
(kPa)
14.9
(103)
Maximum Operating Pressure
PSI
(kPa)
150.0 (1034)
Water Retention Volume Gal
(l)
141.1
(534)
Electrical
Power Supply 208V or 230V / 60 Hz / 3-Phase
Consumption
3
Watts 2500
Minimum Circuit Amps Amps 18.6
MOCP – Max Fuse Size Amps 20
Burner
Burner Input
1
High Fire MBTUh
(kW)
1176
(3454)
Low Fire MBTUh
(kW)
823
(241)
Supply Gas Pressure
Inches W.C.
(kPa)
7 – 10.5
(1.75 – 2.6)
Type Forced Draft with Category I Venting
Gas Dedicated: Natural or Propane. Not convertible.
Ignition Type Intermittent or Interrupted Spark
Flame Detection Optical or UV Scanner
Construction
Dimensions
Width Inches
(mm)
72.4 (1840)
Depth
5
Inches
(mm)
74.8
(1900)
Height
4
Inches
(mm)
94.5
(2400)
Height w/VC
4
Inches
(mm)
111.1
(2820)
Weight
Dry Lbs
(kg)
8600
(3901)
Operating Lbs
(kg)
10450
(4740)
Cabinet
Silver Metallic Pre-Painted Hot Dip Zinc-Aluminum Sheet Steel
Noise Level dB(A) 67
Piping
Chilled / Hot Inches 4 Flanged
Cooling Inches 5 Flanged
Gas Inches 2-1/2 NPT
Flue Diameter Inches
(mm)
7.1
(180)
NOTES: 1. Fuel Input is based on the Higher Heat Value of gas. Burner efficiency = 83%.
2. Pressure Loss ratings are +/- 10%.
3. Power Consumption does not include external pumps or cooling tower fan motors.
4. “Height” does not include level bolts, but “Height w/VC” includes both vent cap and level bolts.
5. “Depth” does not include Junction Box. Add 3.9” to Depth Dimension to include Junction Box.
6. Specifications are based upon water in all fluid circuits and fouling factor of 0.0005 ft
2
-hr-°F/Btu.
7. Minimum cooling water flow is 100%.
