Yealink CP860 User Manual

User Guide for the CP860 HD IP Conference Phone
12
Power over Ethernet
With the included or a regular Ethernet cable, the CP860 IP conference phone can be powered
from a PoE-compliant switch or hub.
To connect the PoE:
1. Connect the Ethernet cable between the Internet port on the phone and an available port
on the in-line power switch/hub.
Note
Connecting the Optional Expansion Microphone CPE80
You can connect optional expansion microphone to enhance the room coverage of the
conference phone.
If in-line power switch/hub is provided, you don’t need to connect the phone to the power
adapter. Make sure the switch/hub is PoE-compliant.
Important! Do not unplug or remove power to the phone while it is updating firmware and
configurations.

Yealink CP860 Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.729ab, iLBC
Handset type	-
Product type	IP Phone
Product color	Black
Display resolution	192 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Networking standards	IEEE 802.1x, IEEE 802.3af
Supported network protocols	IPv4/IPv6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Number of handles included	- pc(s)
Storage temperature (T-T)	10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	260 mm
Width	320 mm
Height	52 mm
