Yealink MVC Series Deployment Guide

| Introduction | 21
Name Description
①
Tracking Mode Key
• For UVC40:
Long press the Tracking Mode key to switch among the auto
framing, the speaker tracking, or off.
• For UVC84/UVC80/UVC50:
Long press the Tracking Mode key to enable/disable the tracking
mode feature; press the Tracking Mode key to wake up the
tracking mode.
②
Mute Key Mute or unmute the microphone.
③
Navigation Key Pan and tilt the camera to adjust the viewing angle.
④
Scroll Wheel
• Scroll up to zoom camera in
• Scroll down to zoom camera out
⑤
Hang up key End a conference call.
⑥
Answer key Answer a conference call.
⑦
Back key /
⑧
Volume Key Adjust the volume.
Technical Specifications
Operating System Windows 10 IoT Enterprise (64-bit)
Software Microsoft Teams Rooms
Processor/SSD/RAM
• Mini-PC: 7th Gen Intel
®
Core
™
i5/128GB/8GB (2 x 4GB)
• MCore: 8th Gen Intel
®
Core
™
i5/128GB/8GB (2 x 4GB)
Mini-PC ports
• 2 x HDMI video output
• Bluetooth and Wi-Fi
• 4 x USB3.0 Type-A
• 1 x 10/100/1000M Ethernet port
• 1 x Power port
MCore ports
• 2 x HDMI video output
• Bluetooth and Wi-Fi
• 1 x Yealink VCH port for connecting MTouch II
• 4 x USB3.0 Type-A
• 1 x 10/100/1000M Ethernet port
• 1 x Power port
• Built-in cable management
Buttons
• Mini-PC: Power On button on the front
• MCore: Power On button on the front

Yealink MVC Series Specifications

General

Category	Conference System
Brand	Yealink
Series	MVC Series
Compatibility	Microsoft Teams
Camera	Yes
Camera Features	Auto-framing
Microphone	Beamforming microphone array
Video Resolution	Up to 4K
Audio Technology	Yealink Noise Proof Technology
Content Sharing	Wireless content sharing
Management	Yealink Device Management Platform
Connectivity	HDMI, USB, Ethernet, Bluetooth, Wi-Fi
Power Supply	AC power adapter
Operating Temperature	0°C to 40°C
Humidity	10% to 90%
