Yealink SIP-T41S User Manual

Basic Call Features
153
Picking Up a Call in the Group
Procedure:
1. Pick up the handset, press the line key or the Speakerphone key.
The GPickup appears on the LCD screen.
2. Press GPickup on your phone when any phone in the group receives an incoming call.
The call is answered on your phone.
You can also use a Group Pickup key (refer to Configuring a Group Pickup Key) to pick up a call
directly.
Note
Anonymous Call
Anonymous call, which is configurable on a per-line basis, allows you to place a call to someone
without revealing your identification by blocking your name or phone number from being
displayed on the called party’s phone screen. You can also configure the phone to send
anonymous call on/off code to the server to activate/deactivate anonymous call on the server
side.
Note
Configuring the Anonymous Call
Procedure:
1. Navigate to Menu->Features->Anonymous.
For the SIP-T42S/T42G/T41S/T41P/T40G/T40P IP phone, navigate to
Anonymous call is not available on all servers. Contact your system administrator for the
anonymous call on code and off code.
The directed call pickup code and group call pickup code are predefined by your system
administrator on the system server.
The call pickup code configured on a per-line basis takes precedence over that configured on a
global basis.
Downloaded from ManualsNet.com search engine

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
