Yealink SIP-T41S User Manual

User Guide for T4 Series IP Phones
26
When there is an active call and a held call, the Calls screen on SIP-T40G/T40P IP phone is
shown as below:
Navigating Menus and Fields
To navigate menus and fields, you can:
 Tap soft keys on the touch screen (on the SIP-T48S/T48G IP phone)
 Tap menu items, fields, and arrows on the touch screen (on the SIP-T48S/T48G IP phone)
 Press soft keys, navigation keys or dialpad keys on the phone (on all IP phones)
To operate your phone, follow these tips:
If you want to
Action
SIP-T48S/T48G
Other IP Phones
Enter the main menu.
Tap Menu.
Press Menu soft key.
Return to the Idle screen.
Tap .
/
Go back to the previous menu.
• Tap .
• Press .
• Press the Back soft key.
Select an item.
• Tap the item.
• Scroll to the item by
pressing or ,
and then press .
• Use the dialpad keys to
select items that have
index numbers.
Scroll through items.
• Tap or to
scroll through items
page by page.
(If you are in the call
history, local directory,
language configuration
screen or ring tones
configuration screen, you
can also press
or .)
Scroll through values for a
field.
• Tap the field’s
highlighted gray box.
• Tap or to scroll
through values page by
• Press or , or
the Switch soft key to
switch among available
values one by one.
Downloaded from ManualsNet.com search engine

Yealink SIP-T41S Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Keypad illumination	Yes
Wi-Fi	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Volume control	Digital
Number of programmable keys	6
Lines quantity	6 lines
Phonebook capacity	1000 entries
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Input frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Certification	CE
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
